Development scale model of steam engine with Stephenson gearing system

Zulhelmi, Zainal (2007) Development scale model of steam engine with Stephenson gearing system. Faculty of Mechanical Engineering, Universiti Malaysia Pahang.


Download (885kB)


This Final Year Project is about development scale model of steam engine with Stephenson Gearing System. Steam engine is device that use steam power to produce mechanical energy for a variety application. In actual operations, steam engine operates with low efficiency because of the bad management of steam intake and steam exhaust at the engine cylinder. This major problem can be encounter by equipping the Stephenson Gearing System at the steam engine. The objectives of this project are to design the steam engine components base on Mechanical Principles of Steam Engine and to investigate the Stephenson Gearing System operation in order to increase steam engine efficiency. All of the designed components are analyze with the calculation analysis of steam engine and the effectiveness of Stephenson Gearing System is showing in the motion simulation of the steam engine. Then best manufacturing process to fabricate this steam engine is discussed and this will help during fabrication session. So, the scale model of steam engine is ready to fabricate if the analysis and simulation on scale model of steam engine produce the positive results.

Item Type: Undergraduates Project Papers
Additional Information: Project paper (Bachelor of Mechanical Engineering) -- Universiti Malaysia Pahang - 2007, SV: NURUL SHAHIDA BINTI MOHD SHALAHIM.
Uncontrolled Keywords: Steam-engine; Design and construction
Subjects: T Technology > TJ Mechanical engineering and machinery
Faculty/Division: Faculty of Mechanical Engineering
Depositing User: Shamsor Masra Othman
Date Deposited: 18 Apr 2012 23:40
Last Modified: 15 Feb 2022 07:44
